Home Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display
Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display
Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display
panels AUO

Original C070VW04 V1 AUO Screen 7.0" 800×480 C070VW04 V1 Display

9999999999999
$142.80
777777777 LED-AUO-LHX-504030-03

Quantity

Sku:

C070VW04 V1

Category:

panels AUO

Tag:
Vendor:

PanelsStock

Type:

100% original

Panel Brand:AUO
Panel Model:C070VW04 V1
Panel Type:a-Si TFT-LCDPanel
Panel Size:7.0"
Resolution:800(RGB)×480 (WVGA)
Display Mode:AMVA, Normally Black, Transmissive
Surface:Antiglare
Brightness:450 cd/m2 (Typ.)
Contrast Ratio:1500 : 1 (Typ.) (Transmissive)
Display Colors:262K (6-bit)
Response Rime:10/25 (Typ.)(Tr/Td) (ms)
Viewing Angle:80/80/80/80 (Typ.)(CR?10) (L/R/U/D)
Frequency:60Hz
Lamp Type:WLED
Signal Interface:Parallel RGB (1 ch, 6-bit)
Input Voltage:3.2/12.5/15/-9V (Typ.)(VDD/AVDD/VGH/VGL)
