Home Brand New Original 7.0"Screen AT070TN84 V.1 LCD Display Panel for Portable DVD GPS Navigation
Brand New Original 7.0"Screen AT070TN84 V.1 LCD Display Panel for Portable DVD GPS Navigation
Brand New Original 7.0"Screen AT070TN84 V.1 LCD Display Panel for Portable DVD GPS Navigation
Innolux , LCD Panel

Brand New Original 7.0"Screen AT070TN84 V.1 LCD Display Panel for Portable DVD GPS Navigation

9999999999999
$46.99 $48.99
777777777

Quantity

Sku:

N/A

Category:

Innolux ,

LCD Panel

Tag:

20250709-17-HSY-300115-ZKL-002

Vendor:

panelsmate

Type:

LCD Screen

Description
Panel model: AT070TN84 V.1
Panel type: a-Si TFT-LCD
Panel size:7.0"(inches)
Width Height Proportion: 16:9
Display Area: 152.40x91.44mm
Visual Area: 155.2x94.2mm
Outline Size:165.0x104.0mm
Resolution: 800*480
Display mode: TN, Normally white, transmission type
Surface treatment: Matte, hard-core coating (3H)
Panel Brightness: 450 cd/㎡(Typ.)
Contrast: 500:1 (Typ.)
Display Color: 262K (6-bit)
Response Time: 10/15 (Typ.) (Tr/Td) (ms)
Visual Angle: 70/70/50/70 (Typ.)(CR≥10) (L/R/U/D)
Scanning Frequency:60Hz
Lamp Type: 3S9PWLED
Signal Connector: Parallel RGB (1 ch, 6-bit)
Connetior: double 30pins
Panel voltage: 3.3/10.4/16.0/-7.0V(Typ.)(VCC/AVDD/VGH/VGL)

Applications: Industrial control, Industrial Monitor, Maintenance for Mechanic, Medical Imaging Systems, Safety Equipment, Military, Bank Terminal, ATM, Ship, Train LCD Media player, Portable DVD, Car Mobile media etc.
