Panel brand: INNOLUX
Panel model: AT080TN52 V.1
Panel type: a-Si TFT-LCD, LCD screen
Panel size: 8.0" (inch)
Active area: 162.0(W) × 121.5(H) mm
Module size: 183.0(W) × 141.0(H) × 5.6(D) mm
Resolution: 800*600
The display mode: TN, Normally White, Transmissive
Surface treatment: Matte, hard-core coating (3H)
Panel brightness: 350 cd/㎡(Typ.)
Contrast:500:1 (Typ.)
Display color: 262K  (6-bit)
Response Time: 10/15(Typ.) (Tr/Td)(ms)
Visual Angle: 70/70/50/70(Typ.) (CR ≧ 10) (L/R/U/D)
Lamp Type: 3S9P WLED
Singal Connector: Parallel RGB ( 1ch, 6/8-bit)
Panel Voltage: 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
